Item	Specification
Material	Imported TPU, special secret formula
Color & Hardness	Yellow 92 Shore A；Red 98 Shore A；Green 64 Shore D
Torque Range	22.4‑2500 Nm
Wear Loss	＜0.05 cm³/1.61km
Operating Temperature	-40℃ ~ +100℃
Standard	Germany KTR Rotex GR series interchangeable

Key Advantages
Long service life: stable operation for 2~5 years under various working conditions, performance close to original KTR Rotex spider
Compensate parallel, angular and axial shaft misalignment
Good elasticity, high tensile strength, wear resistant and corrosion resistant
Maintenance free: no lubrication required, low noise running
Support horizontal, vertical and any flexible installation position
High transmission precision, suitable for high speed rotation
Fast assembly & disassembly, easy onsite replacement

Application Fields
Widely used for motor pump unit, gearbox, hydraulic equipment, conveyor, general industrial machinery, automation drive systems.

Selection Tip
 92ShA Yellow: better vibration damping for general shock load drives
98ShA Red: higher torque capacity for standard industrial transmission
64ShD Green: high rigidity for precision & heavy torque conditions

Inquiry
Please send us your required size, hardness and working condition for quotation.

 FAQ
Q: Is this spider fully interchangeable with KTR Rotex GR?

 A: Yes, dimensionally interchangeable for GR series jaw couplings.
Q: Can you do OEM / custom hardness & color?

 A: OEM & custom molding available upon drawings or samples.
